自动图像分析系统与快速流式细胞术在白细胞减少性疾病诊治中的价值

doi:10.3969/j.issn.1673-8640.2020.04.015

摘要/Abstract

摘要：

目的探讨自动图像分析系统与快速流式细胞术在白细胞减少性疾病诊治中的价值。方法分别采用自动图像分析系统、快速流式细胞术和显微镜镜检法对白细胞计数为（0.5~2.0）×10⁹/L的181例患者进行白细胞分类计数。以显微镜镜检法为参考方法,比较上述方法白细胞分类计数的时间、精密度以及原始细胞检测相关性、敏感性与特异性。结果显微镜镜检法、快速流式细胞术、自动图像分析系统预分类和自动图像分析系统预分类+人工审核白细胞分类计数中位时间分别为864 s、277 s、190 s、364 s;快速流式细胞术中性粒细胞、淋巴细胞、单核细胞和原始细胞分类计数结果的离散度优于其他3种方法。快速流式细胞术、自动图像分析系统预分类、自动图像分析系统预分类+人工审核检测原始细胞的敏感性和特异性分别为94.90%和98.80%、54.08%和74.69%、79.59%和100.00%,与显微镜镜检法的r值分别为0.937、0.507、0.990。结论自动图像分析系统+人工审核与快速流式细胞术可快速、准确地检测出低值白细胞样本中的原始细胞,对患者疾病的诊断、治疗及预后判断具有重要价值。

关键词: 白细胞减少, 自动图像分析系统, 快速流式细胞术

Abstract:

Objective To evaluate the roles of automated image analysis system and CytoDiff flow cytometry for the diagnosis and treatment of leucopenia. Methodse A total of 181 patients with white blood cell count（0.5-2.0）×10⁹/L were enrolled and determined for differentiation and count by automated image analysis system and CytoDiff flow cytometry. Time,precision,correlation of blasts,sensitivity and specificity were compared with microscopy（standard method）. Results The median times were 864,277,190 and 364 s by microscopy,CytoDiff flow cytometry,DM96 preclassification and DM96 reclassification,respectively. The variation of CytoDiff flow cytometry for neutrophils,lymphocytes,monocytes and blasts was better than those of the other 3 methods. The correlation coefficients（r） between CytoDiff flow cytometry,DM96 preclassification,DM96 reclassification and microscopy were 0.937,0.507 and 0.990,respectively. The sensitivity and specificity of CytoDiff flow cytometry were 94.90% and 98.80%,respectively. The sensitivities of DM96 preclassification and DM96 reclassification were 54.08% and 79.59%,and the specificities were 74.69% and 100.00%,respectively. Conclusions DM96 reclassification and CytoDiff flow cytometry can detect blasts in leucopenia samples with high efficiency and accuracy and meet the demand of clinic for the curative effect monitoring and prognostic analysis.

Key words: Leucopenia, Automated image analysis system, CytoDiff flow cytometry

中图分类号:

R446.1

郭平, 陈骊婷, 廖兵, 王剑飚. 自动图像分析系统与快速流式细胞术在白细胞减少性疾病诊治中的价值[J]. 检验医学, 2020, 35(4): 349-353.

GUO Ping, CHEN Liting, LIAO Bing, WANG Jianbiao. Roles of automated image analysis system and CytoDiff flow cytometry for the diagnosis and treatment of leucopenia[J]. Laboratory Medicine, 2020, 35(4): 349-353.

图/表 6

参考文献 17.

1.	BRIGGS C,LONGAIR I,SLAVIK M,et al.Can automated blood film analysis replace the manual differential?An evaluation of the CellaVision DM96 automated image analysis system[J]. Int J Lab Hematol,2009,31(1):48-60.
2.	CORNET E,PEROL J P,TROUSSARD X.Performance evaluation and relevance of the CellaVision DM96 system in routine analysis and in patients with malignant hematological diseases[J]. Int J Lab Hematol,2008,30(6):536-542.
3.	Clinical and Laboratory Standards Institute. Reference leukocyte(WBC) differential counts(proportional) and evaluation of instrumental methods[S]. H20-A2,CLSI,2007.
4.	FUENTES-ARDERIU X,GARCÍA-PANYELLA M,DOT-BACH D.Between-examiner reproducibility in manual differential leukocyte counting[J]. Accred Qual Assur,2007,12(12):643-645.
5.	PAPAKONSTANTINOU A,HEDAYATI E,HELLSTRÖM M,et al.Neutropenic complications in the PANTHER phase Ⅲ study of adjuvant tailored dose-dense chemotherapy in early breast cancer[J]. Acta Oncol,2020,59(1):75-81.
6.	GAJJAR A,RIBEIRO R,HANCOCK M L,et al.Persistence of circulating blasts after 1 week of multiagent chemotherapy confers a poor prognosis in childhood acute lymphoblastic leukemia[J]. Blood,1995,86(4):1292-1295.
7.	VAINSTEIN V,BUCKLEY S A,SHUKRON O,et al.Rapid rate of peripheral blood blast clearance accurately predicts complete remission in acute myeloid leukemia[J]. Leukemia,2014,28(3):713-716.
8.	SHORT N J,BENTON C B,CHEN H C,et al.Peripheral blood blast clearance is an independent prognostic factor for survival and response to acute myeloid leukemia induction chemotherapy[J]. Am J Hematol,2016,91(12):1221-1226.
9.	COVUT F,GUPTA D,PINTO R,et al.Comparison of peripheral blast clearance and day 14 bone marrow biopsy in predicting remission status and survival after 7+3 induction in acute myeloid leukemia[J]. Clin Lymphoma Myeloma Leuk,2019,19(2):73-82.
10.	PALMER L,BRIGGS C,MCFADDEN S,et al.ICSH recommendations for the standardization of nomenclature and grading of peripheral blood cell morphological features[J]. Int J Lab Hematol,2015,37(3):287-303.
11.	ROUSSEL M,DAVIS B H,FEST T,et al.Toward a reference method for leukocyte differential counts in blood:comparison of three flow cytometric candidate methods[J]. Cytometry A,2012,81(11):973-982.
12.	International Council for Standardization in Haematology,Writing Group,BRIGGS C,CULP N,et al. ICSH guidelines for the evaluation of blood cell analysers including those used for differential leucocyte and reticulocyte counting[J]. Int J Lab Hematol,2014,36(6):613-627.
13.	KAHNG J,KIM Y,KIM M,et al.Flow cytometric white blood cell differential using CytoDiff is excellent for counting blasts[J]. Ann Lab Med,2015,35(1):28-34.
14.	FAUCHER J L,LACRONIQUE-GAZAILLE C,FRÉBET E,et al. “6 markers/5 colors” extended white blood cell differential by flow cytometry[J]. Cytometry A,2007,71(11):934-944.
15.	BILLARD M,LAINEY E,ARMOOGUM P,et al.Evaluation of the CellaVision DM automated microscope in pediatrics[J]. Int J Lab Hematol,2010,32(5):530-538.
16.	RÜMKE C L. The imprecision of the ratio of two percentages observed in differential white blood cell counts:a warning[J]. Blood Cells,1985,11(1):137-140.
17.	EILERTSEN H,SAETHER P C,HENRIKSSON C E,et al.Evaluation of the detection of blasts by Sysmex hematology instruments,CellaVision DM96,and manual microscopy using flow cytometry as the confirmatory method[J]. Int J Lab Hematol,2019,41(3):338-344.

方法	中位耗时	最小耗时	最大耗时
显微镜镜检法	864	831	936
快速流式细胞术	277^*	244	302
自动图像分析系统预分类	190^*#	183	230
自动图像分析系统预分类 +人工审核	364^*#△	335	371

方法	中位耗时	最小耗时	最大耗时
显微镜镜检法	864	831	936
快速流式细胞术	277^*	244	302
自动图像分析系统预分类	190^*#	183	230
自动图像分析系统预分类 +人工审核	364^*#△	335	371

方法	中性粒细胞	淋巴细胞	单核细胞	原始细胞
显微镜镜检法	47.00±3.27	26.00±3.46	10.00±2.66	13.00±2.07
快速流式细胞术	43.00±1.13	28.00±0.49	12.00±0.47	13.00±0.50
自动图像分析系统预分类	38.00±1.33	43.00±0.63	4.00±1.17	6.00±0.98
自动图像分析系统预分类+人工审核	42.00±1.47	30.00±3.14	6.00±1.17	16.00±1.33

方法	中性粒细胞	淋巴细胞	单核细胞	原始细胞
显微镜镜检法	47.00±3.27	26.00±3.46	10.00±2.66	13.00±2.07
快速流式细胞术	43.00±1.13	28.00±0.49	12.00±0.47	13.00±0.50
自动图像分析系统预分类	38.00±1.33	43.00±0.63	4.00±1.17	6.00±0.98
自动图像分析系统预分类+人工审核	42.00±1.47	30.00±3.14	6.00±1.17	16.00±1.33

显微镜镜检法	例数	快速流式细胞术		自动图像分析系统预分类		自动图像分析系统预分类+ 人工审核
显微镜镜检法	例数	阳性	阴性	阳性	阴性	阳性	阴性
+	98	93	5	53	45	78	20
-	83	1	82	21	62	0	83
合计	181	94	87	74	107	78	103
